PP Biaxial Geogrid Geocomposite
Biaxial Geogrid Geocomposites is used for soil stabilization/ reinforcement of weak soils that are saturated and susceptible to piping. Biaxial Geogrid Geocomposite have both a high tensile strength and modulus of elasticity, resist damage during installation, and weathering by the atmosphere. BX Geogrid Geocomposite is used for stabilize soils where a both reinforcing and separation between a granular base and very fine soil is required.
Certificate: ISO9001, CE
Features:
- Reducing aggregate fill thicknesses
- Reducing sub-excavation
- Simplifying construction
- Extending service life of pavement
- Reducing labour
- Reducing equipment requirements
- Improving bearing capacity of foundation
- Preventing cracking and subsiding
- Convenient to construct, reducing cost and mantaining expense
Improved performance for:
- Municipal roads
- Highways
- Railway ballast
- Site access roads
- Haul roads
- Parking lots
- Industrial shipping yards
- Foundation footings- and more
Application
• Base reinforcement • Subgrade reinforcement
• Slope reinforcement • Embankment stabilization
• Road Reinforcement • Expressway Reinforcement
• Railway Reinforcement • Port Reinforcement
• Airport Reinforcement • Landfill Reinforcement
• Irrigation Project • Sea Reclamation Project
PP Biaxial Geogrid Composite Geotextile Technical Specifications
|
PP Biaxial Geogrid Composite Geotextile |
|||||
|
No. |
Index Properties |
Test Method |
PPCG2020 |
PPCG3030 |
PPCG4040 |
|
1 |
Polymer |
_ |
PP |
||
|
2 |
Minimum Carbon Black % |
ASTM D4218 |
2% |
||
|
3 |
Tensile Strength @ 2% Strain MD kN/m |
ASTM D6637 |
7.0 |
10.5 |
14 |
|
Tensile Strength @ 2% Strain TD kN/m |
7.0 |
10.5 |
14 |
||
|
4 |
Tensile Strength @ 5% Strain MD kN/m |
14 |
21 |
28 |
|
|
Tensile Strength @ 5% Strain TD kN/m |
14 |
21 |
28 |
||
|
5 |
Ultimate Tensile Strength MD kN/m |
20 |
30 |
40 |
|
|
Ultimate Tensile Strength TD kN/m |
20 |
30 |
40 |
||
|
6 |
Strain @ Ultimate Strength % |
13 |
13 |
13 |
|
|
|
Geotextile physical properties |
|
|||
|
|
Mass per unit area g/m2 |
ASTM D5261 |
140 |
140 |
140 |
|
|
Opening size mm |
ASTM D451 |
0 |
|
|
|
8 |
Dimensions size |
|
|
|
|
|
|
Roll width m |
_ |
3.9 |
3.9 |
3.9 |
|
|
Roll Length m |
_ |
50 |
50 |
50 |
|
|
Roll weight kg |
_ |
80 |
110 |
145 |
Note: MD = Machine Direction; TD = Transverse Direction
Fibtex Laboratory is improving continuously with the purpose of assuring reliable quality.Geotec geosynthetics reserves the right to change the product specifications without further notification.
Package
- Straps for rolls tightening.
- Tape used as per requirement.
Loading Capacity For One 40HC Container
|
Product |
Rolls |
Quantity |
|
GG1515 |
180 |
53,325.0 m2 |
|
GG2020 |
220 |
43,450.0 m2 |
|
GG3030 |
130 |
25,675.0 m2 |
|
GG4040 |
90 |
17,775.0 m2 |
Loading Photos
Additional Info
| Packaging: | Nude | Productivity: | 150,000 sqm / day |
| Brand: | Fibtex | Transportation: | Ocean,Land,Air,Fedex etc. |
| Place of Origin | Shandong, China | MOQ | 1x40HC |
| HS Code | 39269090.90 | Port: | Qingdao |
